Bulk purchases of 3104 aluminum plates are available at more favorable prices, supplied directly from our factory in China. Standard: ASTM B209. Contact us immediately to request a quote.
The 3104 aluminum sheet belongs to the 3000 series Al-Mg-Mn alloys. It is mainly alloyed with manganese (Mn) and magnesium (Mg). This alloy cannot be strengthened by heat treatment, but it offers an excellent balance of strength, corrosion resistance, and formability.
Because of these properties, 3104 aluminum sheeting is widely used in packaging, construction, and industrial manufacturing. It is especially suitable for thin-wall forming applications such as beverage cans. Compared with 3003 aluminum, 3104 aluminum alloy provides higher strength and better deep drawing performance. This makes it a preferred choice for demanding forming processes.
| Alloy Grade | 3104 / AA3104 / EN AW-3104 |
| Temper | O, H12, H14, H16, H18, H19, H22, H24, H26, H28 |
| Thickness | 0.1 mm – 500 mm |
| Width | 100 mm – 2650 mm |
| Length | 500 mm – 16000 mm (custom cut available) |
| MOQ | 1 TON |
| Standards | ASTM B209 / EN 485 / EN 573 / GB/T 3880 |
| Surface Treatment | Mill finish, Anodized, Color coated (PVDF/PE), Embossed, Brushed |
| Al | Balance |
| Mn | 0.8 – 1.4 |
| Mg | 0.8 – 1.3 |
| Si | ≤ 0.6 |
| Fe | ≤ 0.7–0.8 |
| Cu | 0.05 – 0.25 |
| Zn | ≤ 0.25 |
| Others | ≤ 0.15 |
| Temper | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| O | 150 – 210 | ≥ 65 | ≥ 20 |
| H12 | 170 – 230 | ≥ 115 | ≥ 12 |
| H14 | 200 – 260 | ≥ 145 | ≥ 10 |
| H16 | 230 – 290 | ≥ 170 | ≥ 8 |
| H18 | 260 – 320 | ≥ 195 | ≥ 6 |
| H19 | 280 – 340 | ≥ 210 | ≥ 4 |
3104 H19 aluminum sheet is strain-hardened through controlled processing to enhance its mechanical performance. It offers higher tensile strength while maintaining reliable formability, making it an ideal choice for applications that require both strength and precise shaping.
Beverage can bodies (beer, soda)
Can ends and lids
Bottle caps
More than 80% of beverage cans are made from alloys like 3104.
Aluminum louvers and blinds
Roofing sheets
Curtain walls
Color-coated base materials
Lamp holders and bases
Electronic enclosures
Fuel tanks
Heat insulation materials
Stamped containers
Rolling doors
Signboards
Coated aluminum substrates
