Purchase 7005 aluminum plates in bulk from Zggdmetal. Zggdmetal operates a factory offering a comprehensive range of aluminum plate specifications and dimensions, competitive wholesale pricing, and worldwide shipping capabilities.
The 7005 aluminum sheet belongs to the 7000 series aluminum alloys, primarily composed of aluminum, zinc, and magnesium. As a heat-treatable high-strength alloy, it is specifically designed for applications requiring both structural strength and lightweight performance. Compared to the 6000 series, 7005 alloy offers significantly higher strength while maintaining better weldability, making it a preferred material for welded structural components.
High Strength: After heat treatment, 7005 aluminum achieves impressive tensile and yield strength, making it suitable for demanding structural applications.
Excellent Weldability: Unlike other high-strength alloys like 7075 or 2014, 7005 alloy supports reliable welding without significant loss of mechanical properties.
Heat-Treatable: Mechanical performance can be further enhanced through T6 or T651 heat treatment processes.
Good Machinability: The alloy is easy to form, machine, and process, with moderate wear resistance.
Moderate Corrosion Resistance: Offers stable corrosion protection across a variety of environments, with slight variation depending on the temper.
Dimensional Stability: Stress-relieved sheets resist distortion during fabrication and use.
| Alloy | 7005 |
| Temper | O,T6,T651,T73,T74,T7451 |
| Thickness | 0.3mm~600mm |
| Width | 20 mm – 2650 mm |
| Length | 500 mm – 16000 mm (Custom Cut Available) |
| Standard | ASTM B209 |
| MOQ | 2 TON |
| Type | FLAT |
| Origin | CHINA |
| Sample | yes |
| Stock | Available |
| Aluminum (Al) | Balance |
| Zinc (Zn) | 4.0 – 5.0 |
| Magnesium (Mg) | 1.0 – 1.8 |
| Manganese (Mn) | 0.20 – 0.70 |
| Chromium (Cr) | 0.06 – 0.20 |
| Silicon (Si) | ≤0.35 |
| Iron (Fe) | ≤0.40 |
| Titanium (Ti) | 0.01 – 0.06 |
| Zirconium (Zr) | 0.08 – 0.20 |
| Temper | Ultimate Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) |
|---|---|---|---|---|
| O | 150 – 230 | 70 – 120 | 10 – 20 | 40 – 60 |
| T6 | 290 – 350 | 245 – 300 | 8 – 12 | 95 – 115 |
| T651 | 290 – 350 | 245 – 300 | 8 – 12 | 95 – 115 |
| T73 | 280 – 330 | 240 – 280 | 10 – 12 | 90 – 110 |
| T74 | 280 – 330 | 240 – 280 | 10 – 12 | 90 – 110 |
| T7451 | 280 – 330 | 240 – 280 | 10 – 12 | 90 – 110 |
Welded structural components such as trusses, frames, and supports
Large heat exchanger parts
Transport containers and high-load structural assemblies
Bicycle frames and components (particularly T6 temper)
Sporting equipment including tennis rackets and baseball bats
Non-critical aerospace structural components
Mechanical supports and framework structures
7005 t6 aluminum sheet is ideal for engineers and designers seeking a balance of high strength, weldability, and lightweight performance, delivering reliability across both industrial and recreational applications
