Introduction of Zggdmetal 5086 aluminum tube
5086 aluminum tube is a typical aluminum-magnesium anti-rust alloy tube with excellent corrosion resistance, good weldability and medium strength. The alloy further improves its strength in the cold working state and is often used in industrial and military fields that require both structural performance and corrosion resistance.
5086 aluminum tube is widely used in ship structures, marine engineering, automobile and aircraft structures, pressure vessels, refrigeration equipment and other occasions, especially suitable for long-term stable use in harsh environments (such as seawater, hot and humid climates).
Advantages of Zggdmetal 5086 aluminum tube pipe
- Excellent corrosion resistance: strong resistance to seawater, salt spray, and chemical corrosion
- Good weldability: suitable for TIG and MIG welding, excellent strength after welding
- Medium structural strength: meets the load-bearing requirements of most engineering machinery
- Excellent fire and pressure resistance: suitable for military, containers, and high-pressure occasions
- Recyclable materials:environmentally friendly alloys, in line with international export standards
Specifications of Zggdmetal 5086 aluminum pipe tube
| Alloy |
5086 |
| Temper |
O、H112、H116、H111、H321、H32，H36，H38,H116 (special for ship class) |
| Type |
Extruded tube / Welded tube / Seamless tube |
| Outer diameter |
10 mm – 150 mm |
| Wall thickness |
1 mm – 10 mm |
| Length |
1m~6m support customized cutting |
| Surface treatment |
Anodizing, sandblasting, brushing, Seawater resistant coating, etc. |
| Standard |
ASTM B210 / B241 / EN 573 / GB/T 4437 |
Chemical Composition of Zggdmetal 5086 aluminum tube pipe
| Si |
≤0.40% |
| Mg |
3.5–4.5% |
| Fe |
≤ 0.5% |
| Mn |
0.2~0.7% |
| Cr |
0.05~0.25% |
| Cu |
≤ 0.1% |
| Ti |
≤ 0.15% |
| Zn |
≤ 0.25% |
| AL |
Balance |
Mechanical Properties of Zggdmetal 5086 aluminum pipe
| Tensile Strength |
≥ 240 MPa |
| Yield Strength |
≥ 95 MPa |
| Elongation |
≥ 10% |
Applications of Zggdmetal 5086 aluminum pipe
- Hull structure, deck frame, railing pipe, etc.
- Drilling platform, coastal facilities, pontoon structure
- Refrigerated truck, trailer, tanker truck parts
- Chemical tank, gas tank, fire equipment pipe
- Armor structure, missile parts, detection device bracket
- Heat exchanger, evaporator tube, air conditioning structure bracket, etc.
Why choose Zggdmetal ?
- Cutting, bending, drilling and welding on demand
- Attached with material report (chemical composition, performance test) and classification society certification (such as ABS, BV)
- Free samples, small batch quick proofing
- Export professional packaging, support OEM customization
- Technical support team can provide selection suggestions and supporting product solutions
