3003 aluminum tube is AL-Mn rust-proof aluminum alloy tube. 3003 O aluminum tubing improves the mechanical strength of metal through cold working. In the annealed (O) state, it is known for its corrosion resistance, easy processing, weldability and ductility. 3003AL-Mn aluminum alloy tube is a cost-effective and lightweight copper substitute. It is widely used in oil pipelines, heat exchangers and condensers in pressure vessels while maintaining high pressure resistance. The excellent comprehensive performance makes it an ideal material choice in the aerospace and chemical equipment manufacturing fields.
| Description | OD (in) | Wall Thickness (in) |
|---|---|---|
| 3003-H14 1/8″ OD x 0.025″ Wall | 0.125 | 0.025 |
| 3003-H14 3/16″ OD x 0.028″ Wall | 0.1875 | 0.028 |
| 3003-H14 1/4″ OD x 0.035″ Wall | 0.25 | 0.035 |
| 3003-H14 5/16″ OD x 0.035″ Wall | 0.3125 | 0.035 |
| 3003-H14 3/8″ OD x 0.049″ Wall | 0.375 | 0.049 |
| 3003-H14 3/8″ OD x 0.035″ Wall | 0.375 | 0.035 |
| 3003-H14 1/2″ OD x 0.065″ Wall | 0.5 | 0.065 |
| 3003-H14 1/2″ OD x 0.049″ Wall | 0.5 | 0.049 |
| 3003-H14 1/2″ OD x 0.035″ Wall | 0.5 | 0.035 |
| 3003-H14 5/8″ OD x 0.065″ Wall | 0.625 | 0.065 |
| 3003-H14 5/8″ OD x 0.035″ Wall | 0.625 | 0.035 |
| 3003-H14 3/4″ OD x 0.065″ Wall | 0.75 | 0.065 |
| 3003-H14 3/4″ OD x 0.035″ Wall | 0.75 | 0.035 |
| 3003-H14 1.0″ OD x 0.035″ Wall | 1.0 | 0.035 |
| 3003-H14 1.0″ OD x 0.065″ Wall | 1.0 | 0.065 |
| 3003-H14 1.5″ OD x 0.065″ Wall | 1.5 | 0.065 |
| Name | 3003 Aluminum Tube |
| Hot Selling Status | O, H12, H14, H18, H24 |
| Equivalent Name | 3003 A93003 AlMn1 AlMn1 3.0515 3103 ENAW-AlMn1 ENAW-3103 AMTs AlMn 3103 |
| Extruded Aluminum Round Tube | OD: 0.2″–8.0″ (5mm–203mm) WA: 0.02″–0.31″ (0.5mm–8mm) |
| Cold Drawn Aluminum Round Tube | OD: 0.16″–4.0″ (4mm–102mm) WA: 0.02″–0.12″ (0.5mm–3mm) |
| Seamless Aluminum Round Tube | OD: 0.3″–6.0″ (8mm–152mm) WA: 0.03″–0.2″ (0.8mm–5mm) |
| Forged Aluminum Round Tube | Not typically applicable due to alloy characteristics |
| Thin Wall Aluminum Round Tube | OD: 0.2″–4.0″ (5mm–100mm) WA: 0.01″–0.08″ (0.25mm–2mm) |
| Length | Max 12m, fixed length, cut-to-length, or customized |
| Color Options | Silver, natural, black, bronze, champagne, red, blue, or customized |
| Surface Treatment | Anodizing, powder coating, chemical polishing, mill finish, etc. |
| Processing Services | CNC cutting, drilling, slotting, stamping, bending, welding (👉Click for details) |
| Production Process | Extrusion, cold drawing |
| Package | Standard seaworthy export packaging or customized per requirements |
| Applicable Standards | ASTM B210, ASTM B221, ASTM B241, EN 573-3, EN 755-8, GB/T 4437, JIS H4100 (👉Click for details) |
| Fe | ≤ 0.7% |
| Si | ≤ 0.6% |
| Mn | 1~1.5% |
| Cu | 0.05~0.2% |
| Zn | ≤ 0.1% |
| other | Others 0.5% / Others total 0.15% |
| AL | Balance |
| Tensile Strength | ≥ 142~178MPa |
| Yield Strength | ≥ 115MPa |
| Elongation | ≥ 7% |
| Standard System | Designation | Standard Reference |
|---|---|---|
| China (GB) | 3003 | GB/T 3190-1996 |
| International (ISO) | AlMn1Cu | ISO 209.1-1989 |
| Japan (JIS) | A3003 | JIS H4000-1999 / JIS H4100-1999 |
| India (IS) | 31000 | IS 736-2001 |
| Russia (GOST) | AMu / 1400 | GOST 4785-1974 |
| Europe (EN) | EN AW-3003 / AlMn1Cu | EN 573-3:1994 |
| Germany (DIN) | AlMnCu / 3.0517 | DIN 1725-1:1986 |
| France (NF) | 3003 (A-M1) | NFA 50-411 / NFA 50-451 |
| United Kingdom (BS) | 3103 (N3) | BS 1470:1988 |
| United States (AA/UNS) | 3003 / A93003 | Aluminum Association (AA) / UNS A93003 |
