3003 aluminum bar is an aluminum-manganese (Al-Mn) alloy known for its excellent corrosion resistance, good machinability, and superior welding performance. With a typical composition of 96.8–99% aluminum and 1.0–1.5% manganese, it offers medium strength and is non-heat-treatable, relying on cold working to enhance its mechanical properties.
| Alloy | 3003 |
| Temper | O, H12, H14, H16, H18 |
| Equivalent Name | UNS A93003, ASTM 3003 |
| Round Bar Diameter | 0.1 mm – 600 mm |
| Square & Rectangular Bar Size | Customizable dimensions on request |
| Length | 1 m – 12 m, or customized |
| Wall Thickness | For hollow profiles: 0.36 mm – 0.41 mm (typical) |
| Surface Finish | Anodizing, polishing, chemical conversion coating (Alodine), painting, electroplating |
| Shape | Round bar, square bar, rectangular bar, hexagonal bar, custom profiles |
| Standard | ASTM B211 / B221 / B209 / ISO 6361 / GB/T 3880-2006 |
| Payment Methods | T/T, L/C, Western Union, PayPal |
| Packaging | Standard export package: plastic film + waterproof paper + wooden case/pallet |
| Applications | Cookware, roofing, chemical equipment, heat exchangers, storage tanks, decorative parts |
| Shape / Type | Size Range (Metric) | Size Range (Imperial) | Length Availability | Temper Options | Wall Thickness (if applicable) | Notes |
|---|---|---|---|---|---|---|
| Round Bar / Rod | Ø 3 mm – Ø 800 mm | Ø 1/8″ – Ø 31.5″ | 1000 mm – 12,000 mm (customizable) | O, H12, H14, H16, H18, H112 | N/A | Commonly used in machining, structural parts, tanks, and architectural uses |
| Square Bar | 4 mm × 4 mm – 100 mm × 100 mm | 5/32″ × 5/32″ – 4″ × 4″ | 1000 mm – 6000 mm | O, H12, H14, H16, H18 | N/A | Ideal for framework, support components, decorative trim |
| Rectangular Bar / Flat Bar | Thickness: 2 mm – 100 mm; Width: 10 mm – 500 mm | Thickness: 0.08″ – 4″; Width: 0.4″ – 19.7″ | 1000 mm – 6000 mm | O, H12, H14, H16, H18 | N/A | Widely used in panels, supports, heat exchanger parts |
| Hexagonal Bar | Across Flats: 2 mm – 100 mm | Across Flats: 5/64″ – 4″ | 1000 mm – 6000 mm | O, H12, H14, H16, H18 | N/A | Preferred for fasteners, machine parts requiring wrench grip |
| Cold Drawn Round bar | OD: 4.8 mm – 101.6 mm | OD: 3/16″ – 4″ | Cut-to-length or standard 6 m | O, H14 | 0.56 mm – 2.1 mm (0.022″ – 0.083″) | Smooth interior, ideal for fluid transfer, structural frames |
| Telescoping Round bar | OD: 1.6 mm – 15.9 mm | OD: 1/16″ – 5/8″ | 305 mm (1 ft) & 1829 mm (6 ft) options | H14 | 0.36 mm – 0.41 mm (0.014″ – 0.016″) | Designed for adjustable tubing assemblies, display stands |
| Custom Profiles | Based on drawings, including half-round, angle, or T-profiles | — | As required | All cold-worked tempers | Varies | Tailored to specific structural or decorative needs |
| Element | Content (%) |
|---|---|
| Aluminum (Al) | 96.8 – 99.0 |
| Manganese (Mn) | 1.0 – 1.5 |
| Copper (Cu) | ≤ 0.05 – 0.20 |
| Iron (Fe) | ≤ 0.7 |
| Silicon (Si) | ≤ 0.6 |
| Zinc (Zn) | ≤ 0.10 |
| Others (Each) | ≤ 0.05 |
| Others (Total) | ≤ 0.15 |
| Property | Value |
|---|---|
| Tensile Strength | 130 – 200 MPa (19 – 29 ksi) |
| Yield Strength | ≥ 110 MPa (16 ksi) |
| Elongation (%) | ≥ 10 (depends on thickness & temper) |
| Brinell Hardness (HB) | ~ 40 – 50 |
| Density | 2.73 g/cm³ |
| Melting Point | 643 – 654 °C |
| Modulus of Elasticity | ~ 69 GPa |
| Poisson’s Ratio | 0.33 |
ZGGDMETAL offers high-quality aluminum bars directly from the factory, ensuring competitive pricing and consistent quality through strict quality control and SGS/ISO certifications. With fast delivery and a strong global logistics network, we guarantee timely shipments worldwide. Our team provides OEM and customization services, including tailored dimensions, temper options, and even logo printing, to meet specific project needs. Choosing ZGGDMETAL means partnering with a supplier committed to reliability, flexibility, and customer-focused service.
