Why Choose ZGGDMETAL’s 1100 Aluminum Tube?
Global Aerospace Standard Compliance
ZGGDMETAL’s 1100 aluminum tubes meet or exceed the requirements of major international standards, including:
- WW-T-700/1 – Seamless drawn aluminum tubing, 1100-H14
- AMS 4062 – Tubes for low-pressure fuel/gas lines and hydraulic piping
- ASTM B210/B210M-19a – Seamless drawn aluminum and aluminum-alloy tubes
- EN 573-3:2013 – Chemical composition standards for European markets
- JIS H 4000:2006 – Japanese industrial aluminum alloy specifications
- GB/T 3191-2018 – National standard of China for aluminum tubing
Certified Quality Systems
- AS9100 Aerospace Quality Certification
- NADCAP High-Temperature Processing
- NADCAP Non-Destructive Testing
- ISO 9001, ISO 14001, IATF16949, OHSAS 18001
1100 Aluminum Tubes Stock Dimensions – Hot-Selling Sizes
We maintain a wide inventory of 1100 O/H14/H18/H112 aluminum tubes. All sizes are available in fixed lengths (3,000 mm or 4,000 mm) or in coil form, and can be customized upon request.
| OD (mm) |
Wall (mm) |
OD (mm) |
Wall (mm) |
| 6.04 |
0.4 |
15.88 |
1.65 |
| 7.0 |
0.4 |
16.0 |
1.5 / 2.0 |
| 8.0 |
0.4 / 0.5 / 1.0 |
18.0 |
1.5 / 2.0 |
| 9.0 |
2.0 |
19.05 |
1.65 |
| 9.53 |
1.0 |
10.0 |
1.25 / 1.65 |
| 11.0 |
1.8 |
12.0 |
1.75 / 2.0 |
| 12.7 |
1.2 |
14.0 |
1.75 |
👉 Custom dimensions and cut-to-length service are available. Contact us for a Quick Quotation.
Specs of 1100 Aluminum Tubing
| Alloy |
1100 |
| Temper |
O, H14, H18, H112 |
| OD Range |
4.0 mm – 130 mm |
| Wall Thickness |
0.4 mm – 10 mm |
| Length |
3,000 mm / 4,000 mm / coil |
| Process |
Extruded or Seamless Drawn |
| Standards |
WW-T-700/1, AMS 4062, ASTM B210, EN 573-3, JIS H4000, GB/T 3191 |
| MOQ |
1 ton (LCL); 12 tons (20FT); 24 tons (40FT) |
| Surface Finish |
Mill, Anodized, Brushed, Powder Coated |
| Color Options |
Natural, Black, Silver, Bronze, Champagne, Custom |
Chemical Composition of 1100 Aluminum Alloy Pipe
| Element |
Content (%) |
| Si |
≤ 0.95 |
| Fe |
— |
| Cu |
0.05 – 0.20 |
| Mn |
≤ 0.05 |
| Zn |
≤ 0.10 |
| Al |
Balance |
Mechanical Property of 1100 Aluminum Tube
| Temper |
Tensile (MPa) |
Yield (MPa) |
Elongation % |
Brinell Hardness |
Shear Strength (MPa) |
| O |
90 |
35 |
≥23 |
35 |
60 |
| H14 |
125 |
115 |
≥9 |
32 |
75 |
| H18 |
165 |
150 |
≥5 |
44 |
90 |
Other Properties:
-
Density: 2.71 g/cm³
-
Melting Range: 640°C – 655°C
-
Thermal Expansion: 23.6 µm/m·K (20–100°C)
-
Thermal Conductivity: 222 W/m·K (O temper)
-
Electrical Conductivity: 34 MS/m (O), 33 MS/m (H18)
Advantages of ZGGDMETAL‘s 1100 Aluminum Tube
- Excellent corrosion resistance
- Easy to process, excellent formability
- Suitable for a variety of welding processes
- Easy to regenerate and recycle
- Meet the needs of cold processing pipe making
Chemical Composition of ZGGDMETAL 1100 Aluminum Tube
| Aluminum |
Al |
99.00% |
| Silicon |
Si |
≤ 0.45 |
| Copper |
Cu |
0.05 – 0.20 |
| Zinc |
Zn |
≤ 0.01 |
| Manganese |
Mn |
≤ 0.035 |
| Vanadium |
V |
≤ 0.05 |
| Iron |
Fe |
≤ 0.35 |
Mechanical Properties of ZGGDMETAL 1100 Aluminum Tube
| Tensile Strength |
≥ 110 MPa |
| Yield Strength |
≥ 170 MPa |
| Elongation |
3~5% |
Applications of ZGGDMETAL 1100 Aluminum Tube
Zggdmetal’s 1100 aluminum tubing is engineered for critical aerospace, industrial, and thermal transfer applications:
- Aerospace: Oil lines, hydraulic piping, fuselage reinforcement, aircraft tanks.
- Automotive: Fuel delivery systems, lightweight supports.
- HVAC: Thermal transfer tubes, AC heat pipes, cable shielding.
- Industrial Equipment: Food processing machines, chemical tanks, marine pipes.
- Heat Exchangers: Seamless or welded tubes tailored for precise thermal performance.
1100-H14 seamless drawn tubes are widely used in lightweight aerospace structural systems due to their high strength-to-weight ratio and excellent formability.
1100-H18 is ideal for high-hardness and wear-resistant applications such as marine fittings or processing plants.
1100-O / H112 are best suited for flexible forming in refrigeration and HVAC systems, with enhanced conductivity and machinability.
What should I pay attention to when buying 1100 aluminum tubes?
- Specification requirements: Choose the appropriate specifications according to the required environment and requirements, including diameter, wall thickness, length, etc.
- Tempering requirements: Choose the appropriate state according to the actual use needs, for example, O state aluminum tubes are suitable for bending and forming, while H14 state aluminum tubes are suitable for occasions with higher strength requirements.
- Check quality: Check whether the surface of the aluminum tube is smooth, free of cracks, oxidation, damage, etc., to ensure that the quality meets the requirements.
- Supplier selection: Choose suppliers with credibility, production qualifications, and perfect after-sales service to purchase, to ensure the reliability of product quality and after-sales service. Quick quotation
- Logistics and transportation: Be careful during transportation to avoid damage to the aluminum tube by impact, friction, etc., and prevent deformation during transportation to ensure product quality.
